The Bookeye
®
3 R1 is outfitted with a motorized book cradle that
includes three types of adjustment controls. Press a a button and the
adjustable cradle plates bring both sides of an open book to the
same level under the glass plate, allowing the camera to capture the
document with optimal clarity. The cradle plates also optimally adjust
to the width of the book´s spine without exerting unnecessary
pressure on the book. Documents remain in their ”natural” state on
the scan surface and don‘t need to be unbound or positioned.
R1 Model
Book Scanners
18
Highlights
Color overhead scanner for formats up to A1+ (also avail-
able as a grayscale system), 400 dpi optical resolution
Motorized book cradle with lift up to 10 cm
Glass plate for perfect scans
LED lamps, no warm up, IR/UV free
Book Fold Correction
Remote maintenance and analysis, web based firmware
updates
Digital color balance
Automatic white balance and black value
Scan2PDF - Create PDF/A Formats
Easy installation via Scan2Net
®
List Price: $ 27,950
Scanner Optics CCD camera, scans in color, grayscale, B&W
Resolution
300 x 400 dpi optical resolution
400 x 400 scan resolution
Document Size 630 x 900 mm (24.8 x 35.5 inch) > DIN A1
Fastest Speed DIN A1+ @ 400 dpi: 7 seconds
Color Depth
36 bit color, 12 bit grayscale
Scan Output
24 bit color, 8 bit grayscale, bitonal, enhanced
halftone
Output Formats PDF, PDF/A, JPEG, PNM, TIFF
uncompressed, TIFF G4 (CCITT)
Dimensions
1250 x 1500 x 780 mm (49.2 x 59 x 30.7 inch)
(with lamps)
Weight
~80.5 kg (177.1 lbs.)
Power
Consumption
0.1 W (Standby) / 105 W (Ready to scan) /
275 W (Scanning)
