Bookeye
®
4 Basic is an entry level book scanner but still a full-
fledged member of the Bookeye family, for use anywhere where
grayscale is enough. Equipped with a standard scanning application
available via the large color touchscreen, Bookeye
®
4 Basic scans
magazines, files, folders, loose or bound documents at an optical
resolution of 400 dpi at high speeds. Images can be stored to a USB
disk or sent via eMail, uploaded to an FTP server, printed to any
network or connected printer or saved on a network drive.
The client interface is optional.
Basic
Book Scanners
12
Highlights
Overhead grayscale book scanner for formats up to A2+,
400 optical dpi
LED lamps, no warm up, IR/UV free
Large color WVGA touchscreen
V-shaped book cradle 120 - 180 degrees
Book Fold Correction - Scan bound documents without
annoying shadows
Automatic finger and thumb removal, automatic crop &
deskew
Digital color balance, automatic white balance and black
value
Easy installation via Scan2Net
®
technology
List Price: $ 12,950
Scanner Optics CCD camera, scans in grayscale, B&W
Resolution
400 dpi optical resolution
400 x 400 scan resolution
Document Size 460 x 620 mm (18 x 24.4 inch) > DIN A2
Fastest Speed
DIN A2+ @ 150 dpi: 1.2 seconds
Color Depth
12 bit grayscale
Scan Output
8 bit grayscale, bitonal, enhanced halftone
Output Formats PDF, PDF/A, JPEG, PNM, TIFF
uncompressed, TIFF G4 (CCITT)
Dimensions
795 x 670 x 670 mm, 31.3 x 26.4 x 26.4 inches
Weight
~39,5 kg (87 lbs.)
Power
Consumption
<= 0.5 W (Sleep) / 2.5 W (Standby) /
75 W (Ready to scan) / 130 W (Scanning)
