WideTEK
®
36DS is the world´s first wide format duplex
scanner for digitizating two sided printed documents up to 36
inches (915 mm) wide. At 300 dpi optical resolution, the scanner
needs only 2.5 seconds to scan the front and back of a newspaper
page in a single pass through the scanner. The scanner has two
camera boxes, each holding three CCD systems. After scanning,
software separates the scan into four single images; capturing the left
and right half of the front and back of the newspaper - everything in
one single step.
8
Wide Format Scanners
Highlights
Scans double sided documents up to 36 inches wide in a
single pass, 1200 x 600 optical dpi
2.5 seconds at 300 dpi for front and back sides of a
newspaper page
Twice the scanning power for volume applications
Software splits double sided scans into 4 images
Fastest color scanning, 12.4 inches per second
LED lamps, no warm up, IR/UV free
Large touchscreen for simple operation
Face up scanning, integrated walk up scanning software
Easy installation via Scan2Net
®
technology
List Price: $ 25,450
Scanner Optics CCD camera, scans in color, grayscale, B&W
Resolution
1200 x 600 dpi optical resolution
1200 x 1200 scan resolution
Document Size 965 mm, 38 inch width, nearly unlimited length
Fastest Speed 200 dpi - 18.9 m/min (12.4 inch/sec)
Color Depth
36 bit color, 12 bit grayscale
Scan Output
24 bit color, 8 bit grayscale, bitonal, enhanced
halftone
Output
Formats
PDF, PDF/A, JPEG, PNM, TIFF
uncompressed, TIFF G4 (CCITT)
Dimensions
220 x 1094 x 685 mm, 9 x 43 x 27 inches
Weight
~64 kg (141 lbs.)
Power
Consumption
0.1 W (Sleep) / 8 W (Standby) /
120 W (Ready to scan) / 200 W (Scanning)
