The WideTEK
®
48 wide format CCD scanner scans documents up to
48 inches wide (1220 mm) quietly and astonishingly fast. Using the
touchscreen display, up to 30 different password protected jobs can
be defined and stored. Cutting edge camera technology, consisting
of a dust-protected, sealed camera box holding CCD systems using
a patented stitching procedure, delivers 1200 x 600 dpi resolution.
Walk up scanning software allows users to simply walk up, scan and
store or send the image, all through the use of the touchscreen.
Wide Format Scanners
11
Scanner Optics CCD camera, scans in color, grayscale, B&W
Resolution
1200 x 600 dpi optical resolution
1200 x 1200 scan resolution
Document Size 1270 mm, 50 inch width, 48 inch scan width,
nearly unlimited length
Fastest Speed 200 dpi - 14.2 m/min (9.3 inch/sec)
Color Depth
36 bit color, 12 bit grayscale
Scan Output
24 bit color, 8 bit grayscale, bitonal, enhanced
halftone
Output
Formats
PDF, PDF/A, JPEG, PNM, TIFF
uncompressed, TIFF G4 (CCITT)
Dimensions
220 x 1399 x 555 mm, 9 x 55 x 22 inches
Weight
~56 kg (123 lbs.)
Power
Consumption
0.1 W (Sleep) / 4 W (Standby) /
70 W (Ready to scan) / 110 W (Scanning)
Highlights
For high resolution scans up to 48 inches (1220 mm) in
width, 1200 x 600 dpi optical
Automatic crop & deskew
On the fly rotation while scanning, face up scanning (no
more "blind"scanning)
Real time display of scanned images, modify images
without rescanning
Standalone device with its own integrated PC
LED lamps, no warm up, IR/UV free
Large touchscreen for simplified operation
Easy installation via Scan2Net
®
technology
List Price: $ 15,990
